The Yokogawa GX10-1E is an industrial paperless data recorder featuring a 5.7-inch color touchscreen, 10-channel universal analog input configuration, and Ethernet communication. It supports real-time data acquisition, historical trend monitoring, mathematical calculations, advanced security functions, and OPC-UA server communication for industrial process monitoring.
It is used in manufacturing process control, temperature and pressure monitoring, pharmaceutical production, laboratory testing, industrial equipment monitoring, and automated data acquisition systems.
Condition: Used
What's included: Yokogawa GX10 paperless recorder assembly, as pictured
Manufacturer: Yokogawa Electric Corporation
Model: GX10
Part Number: GX10-1E /MT/MC/US10/AS/E3
Product Type: Industrial Paperless Data Recorder
Product Family: SMARTDAC+
Display Size: 5.7-Inch Color TFT Touchscreen
Display Resolution: 640 × 480 Pixels
Analog Input Channels: 10
Input Terminal Type: M3 Screw Terminals
Input Types: DC Voltage, Thermocouple, RTD, Digital Input
Mathematical Functions: /MT Math and Report Functions
Communication Channels: /MC Communication Channel Function
Security: /AS Advanced Security Functions
OPC-UA: /E3 OPC-UA Server Function
Communication Interface: Ethernet
Ethernet Speed: 10/100 Mbps
Internal Memory: 500 MB Flash Memory
External Storage Support: SD/SDHC Memory Cards up to 32 GB
Power Supply: 100–240 VAC
Frequency: 50/60 Hz
Maximum Power Consumption: 60 VA
Mounting Type: Panel Mount
Style: H2 / S4
Serial Number: S5V306202
Country of Manufacture: China
Applications: Industrial Data Acquisition, Process Monitoring, Temperature Recording, Manufacturing Quality Control, Laboratory Testing
The Yokogawa GX10-1E is an industrial paperless data recorder featuring a 5.7-inch color touchscreen, 10-channel universal analog input configuration, and Ethernet communication. It supports real-time data acquisition, historical trend monitoring, mathematical calculations, advanced security functions, and OPC-UA server communication for industrial process monitoring.
It is used in manufacturing process control, temperature and pressure monitoring, pharmaceutical production, laboratory testing, industrial equipment monitoring, and automated data acquisition systems.
Condition: Used
What's included: Yokogawa GX10 paperless recorder assembly, as pictured
Manufacturer: Yokogawa Electric Corporation
Model: GX10
Part Number: GX10-1E /MT/MC/US10/AS/E3
Product Type: Industrial Paperless Data Recorder
Product Family: SMARTDAC+
Display Size: 5.7-Inch Color TFT Touchscreen
Display Resolution: 640 × 480 Pixels
Analog Input Channels: 10
Input Terminal Type: M3 Screw Terminals
Input Types: DC Voltage, Thermocouple, RTD, Digital Input
Mathematical Functions: /MT Math and Report Functions
Communication Channels: /MC Communication Channel Function
Security: /AS Advanced Security Functions
OPC-UA: /E3 OPC-UA Server Function
Communication Interface: Ethernet
Ethernet Speed: 10/100 Mbps
Internal Memory: 500 MB Flash Memory
External Storage Support: SD/SDHC Memory Cards up to 32 GB
Power Supply: 100–240 VAC
Frequency: 50/60 Hz
Maximum Power Consumption: 60 VA
Mounting Type: Panel Mount
Style: H2 / S4
Serial Number: S5V306202
Country of Manufacture: China
Applications: Industrial Data Acquisition, Process Monitoring, Temperature Recording, Manufacturing Quality Control, Laboratory Testing
