Excelitas Miniature Xenon Flashlamp RSL-3101-30
Key Input / Output & Operating Condition Specifications
Input Voltage: 11-28 VDC (Nominal 24 VDC)
Input DC Current: 0.2 Amps RMS
Peak Current: 1.0 Amp
Trigger: +5V, 10-50mA Peak Input, 100-100us Pulse Width
Output Voltage: 100-600 _/-2% VDC (adjustable)
Power: 2 Watts Max
Flash Rate (Hz): Fmax=2/E, where E=1/2V^2
Spectral Range: 190-2000+ nm
Stability: <3% CV
Min Lifetime: >1x10^8 Flashes
Operating Temperature: 32-104degF
Item comes as pictured in its present condition with no additional accessories unless stated.
_____________________________________________________
Payment
Full payment is Due within 2 business days of sale.
Warranty and Returns
30 Day Return Warranty
AS-IS items are sold without warranty
Shipping and Handling
-Most items are Shipped within 1 Business Day if payment cleared by 12pm Pacific Time-
-All items are packaged with care to ensure full protection during transit-
-We ship with Fedex, UPS and USPS unless requested otherwise-
-Freight shipments require longer handling time-
-International shipping is available! Contact us for a Quote(buyer is responsible for taxes, duties import charges)-
Excelitas Miniature Xenon Flashlamp RSL-3101-30
Key Input / Output & Operating Condition Specifications
Input Voltage: 11-28 VDC (Nominal 24 VDC)
Input DC Current: 0.2 Amps RMS
Peak Current: 1.0 Amp
Trigger: +5V, 10-50mA Peak Input, 100-100us Pulse Width
Output Voltage: 100-600 _/-2% VDC (adjustable)
Power: 2 Watts Max
Flash Rate (Hz): Fmax=2/E, where E=1/2V^2
Spectral Range: 190-2000+ nm
Stability: <3% CV
Min Lifetime: >1x10^8 Flashes
Operating Temperature: 32-104degF
Item comes as pictured in its present condition with no additional accessories unless stated.
